Falcon-10
The Falcon 10 is a small electric unmanned helicopter with a unique folding design that reduces the volume of the platform by 80%, making it highly convenient for transportation and storage.
Falcon-10 Overview
The Falcon 10 is a small electric unmanned helicopter with a unique folding design that reduces the volume of the platform by 80%, making it highly convenient for transportation and storage. The aircraft can be assembled in less than 5 minutes and operated by a single user.
The helicopter UAV features a datalink that provides real-time HD image transmission at distances of up to 15 km, and incorporates frequency hopping for robust anti-jamming as well as AES-256 encryption. The Falcon 10 can be equipped with a wide range of payloads, including EO/IR gimbals, multispectral and hyperspectral cameras, searchlights, lifebuoys, and megaphones. It can also be integrated with custom third-party equipment for unique mission requirements.
Falcon-10 SPECIFICATIONS
| Dimensions | Without rotor blades: 1655*565*580mm |
|---|---|
| Max Take-off Weight | 25kg |
| UAV Weight | 10.6kg |
| Max Payload | 7kg |
| Cruising Speed | 60-90km/h (max 130km/h) |
| Wind Resistance | Level 7 (wind speed 17m/s) |
| Endurance | 50 min (without payload) |
| Max Operating ASL Altitude | 5100m |
Falcon-10 Accessories
Falcon-10 complete platform 1 Unit
• Handheld Ground Control Station 1set(Including ground station control software)
• Main Rotor Blade 1set
• Tail Rotor Blade 1set
• General tool box 1set
• Ground system integration box 1set
（Including batteries）
• Tripod 1set
• Tripod cloud platform 1set
• Tripod extension rod 1pcs
• Power battery 1set
• Power battery charger 1set
• Power battery charging transfer line 1set
• Ground system integration box charger 1set
