GDU S400E
Versatile Efficiency Enhancer
S400E can fly 58 mins max, so you can take more pics, scan a larger area, or inspect more solar panels with the extended uptime.
GDU S400E Overview
S400E is engineered with a compact design configurable with a variety of payloads, so you can enhance your efficiency in more than just one scenario, be it scanning a building with LiDAR, or finding structual damages with an infrared camera.
GDU S400E SPECIFICATIONS
| Dimensions | Folded (with propellers): 347×367×424mm (L×W×H) Unfolded (with propellers): 950×995×424mm (L×W×H) Unfolded (without propellers): 549×592×424mm (L×W×H) |
|---|---|
| Flight Time | 58 minutes (No load) |
| Symmetrical Motor | Diagonal Distance: ≤ 725mm |
| Weight | 2.35kg (excluding batteries) |
| Maximum Takeoff Weight | 7kg |
| Maximum Payload | 3kg (Under the maximum payload, the maximum safe flight speed is only 15m/s) |
| Noise | ≤ 58dB@5m position |
| Propeller | 1866 folded propellers |
| Speed & Resistance | Maximum pitch angle: 30° (45° during emergent braking and startup) Maximum ascent speed: S mode: 5 m/s, P mode: 4 m/s Maximum descent speed: S mode: 4 m/s, P mode: 3 m/s Maximum wind resistance: 15 m/s (Level VII) Maximum wind resistance during takeoff and landing: 12m/s Maximum flight speed: S mode: 23 m/s, P mode: 15 m/s |
| Remote Controller | Display: 7.02-inch touch LCD display with a resolution of 1920 × 1200 Brightness: 1000 cb/m2 Dimensions (folded antenna): 268x139x103 mm (LxWxH) Weight: Approx. 1 kg (excluding external battery), Approx. 1.25 kg (with external battery) Batteries: Internal: Li-ion: 7000mAh@7.2V, External: Li-ion: 7000mAh@7.2V Battery Life: Internal battery: 3 hours, With external battery: 6 hours IP Rating: IP54 Operating Temperature: -20℃~50℃ |
GDU S400E Accessories
Key Features - IN THE BOX
- Aircraft(with propellers) x1
- Intelligent smart battery x1
- Remote controller x1
- RTK antennas subassembly x1
- Spare propellers x1
- AC charger x1
- Safety transport box x1
- Tool kit x1
- Manuals x1
